baxter AK 98 - Rear Components and Connectors

8
MACHINE EXTERNAL COMPONENTS | Fluid Part
1. Stand-by ports for dialysis fluid tubes
2. Dialysis fluid tube from machine to dialyzer (blue)
3. Dialysis fluid tube from dialyzer to machine (red)
4. Stand-by port for red concentrate connector
5. Stand-by port for blue concentrate connector
6. Concentrate connector, red
7. Concentrate connector, blue
1
7
4
5
6
2
3
HC10139 |
