10
SETUP GUIDE WITH HASP CONT.
Lift the monitor face/vacuum form up
towards the monitor. Route all wires
through the rear before pinching them.
Rehook the latches in the top rear of the
cabinet to secure the face in place.
Plug the top marquee light cable (CE5931)
into CE5932.
Secure the hasp piece in place using the
four included bolts and washers. Tighten
in place.
