TROUBLESHOOTING GUIDE
9
Problem Probable Cause Remedy
LED white lower
cabinet lighting
not working.
LED’s to light up playfield
receive 12 Volts DC from
power supply through the
Power Distribution Board.
Check for proper connection from power supply to Power
Distribution Board and then to LED strips.
Check continuity. (AACE5936, AACE5936, AACE5934,
AAPS1013-PTL)
Refer to “AC In, Power Supply Wiring Diagram section”
Colored
cabinet lighting
not working.
If all colored cabinet lights
are not functioning, check
Light Board (AACB5900)
If LED strip is out, check
cable. Refer to “Light
Board Wiring Diagram”
Faulty LED
Faulty Minigen Board
Check power to Light Board from Power Distribution
Board. Cable # AACE5915. Check ribbon cable to Light
Board from Newgen Board. Cable # AACE5933
Check for proper connection from Light board to LED
strips. Check continuity. Refer to “Light Board
Wiring Diagram”
Swap LED connector from one socket to the other to
verify. Replace LED (AACE8622)
Replace Minigen board. (AANEWGEN1-PJ/RBN)
White LED’s
around monitor
do not work.
Faulty Cable
Faulty LED
Check for proper connection from Light board to LED
strips. Check continuity. (AACE5930, AACE5901)
Swap LED connector on Light Board to verify.
Replace LED if needed. (AACE5930)
Marquee Lights
are not on.
Faulty Cable
Faulty LED
Check for proper connection from Power Distribution board to
LED strips. Check continuity. (AACE5931, AACE5932)
Replace LED (AACE5931)
Menu Buttons do
not work.
Swap connectors at the 2
buttons.
Pinched, broken, or
disconnected wiring
Main board faulty.
Replace button if problem stays with button.(AAPB2700)
Inspect crimp to ensure good connection.
Check connections from menu buttons to main board.
Check continuity on wires. (AAPB2700, AACE5910)
Replace Newgen Board. (AANEWGEN1-PJ/RBN)
Colored LED’s
around monitor
do not work.
Faulty Cable
Faulty LED
Faulty Chase Board
Check for proper connection from Chase Board to LED strips.
Check continuity. (AACB5935, A5CB5901, AACE5918)
Refer to “Coin Mech, Menu & Counter Wiring Diagram”
There are 10 LED blocks in series that surround the monitor. If
one LED block is faulty, the following LED blocks will not work.
Red Led on board only blinks at power on. Verify 12 volts to
board from Power Distribution Board. Check cable AACE5920
Replace Chase board if needed. (AA9503-PTL)
