WIRING DIAGRAMS
COIN MECH, MENU & COUNTERS WIRING
AANEWGEN1-PJ/RBN
Game Stop Light
A5PB5900
+ 12 V
COM
+ 12 V
COM
AACE5912
To Power IN
(J18) from
power board.
T
o
J
2
2
o
n
M
a
i
n
B
o
a
r
d
Menu
Select
Menu
Button
AAPB2700
AAPB2700
AACE5911
To Ticket
Dispenser
Part # A5TD1
Notch Signal
Com Ground
Enable Signal
12 Volt Power
Low Ticket Switch
Wired Normally Open
AASW200
1/4” Spacer A5SENY020
AACE5911
To J5 on
main board
To J9 on
main board
Speaker
AACE8811
A
A
C
E
5
9
0
8
To J24
on main
board.
Wires to switch come
from the motherboard.
Switch is wired
normally open.
AACE5910
Game
Counter
Ticket
Counter
AACO1000
AACB5900
Light Board
AACE5933
To J19
on main
board.
T
o
J
2
2
o
n
M
a
i
n
B
o
a
r
d
AACE5909
AACE5910
