Overview
2-6 User Manual
DMR V4C 3.3 (User Manual) V-4 06-May-2022
2.7 Specifications
2.8 Environmental and Storage Conditions
WARNING:
Read and take account of the environmental condition ranges for proper operation before using
the V4C-O2E Oxygen Mixer.
10 Oxygen inlet module Connection point to oxygen hose.
11 Air intake and air intake filter Location where air is drawn into the system. Filters air as it enters the Oxygen
Mixer.
Table2-2.Figure 2-2 legend
Call-out
Number
Feature
Description
Table2-3.V4C-O2E Oxygen Mixer specifications
Parameter
Value
V4C-O2E Oxygen Mixer weight 2.75 kg (6 lbs)
V4C-O2E Oxygen Mixer dimensions 383 x 264 x 309 mm
Connectors
Gas connection tubing: male 22 mm (OD) conical
Oxygen inlet connection: Male CGA DISS-type body, No. 1240
connector
Inspiratory bacteria filter requirements
See the list of acceptable inspiratory filters in the manual of the
compatible ventilator.
Maximum allowable flow resistance when using the Oxygen
Mixer:
Adult: 2.9 cmH2O at 60 lpm
Pediatric: 3.0 cmH2O at 30 lpm
V4C-O2E Oxygen Mixer air intake filter
See Baylis Medical V4C-O2E Air Intake Filter (HW01XXXXFMINT)
in Section 11, Unpacking and Accessories.
Compatible ventilators
Baylis Medical V4C-560 Ventilator bearing the O2E connector
on the back panel. See Section 2.4, Compatible Ventilators for
more information.
Oxygen source requirement
20-80 psi (138-551 kPa)
Minimum flow rate 70 lpm
