Installation and Assembly
4-8 User Manual
DMR V4C 3.3 (User Manual) V-4 06-May-2022
Figure4-8.Installing V4C-O2E Oxygen Mixer connections and air intake filter
Figure4-9.Gas connection tube and adapter connected to the ventilator
Table4-1.Figure 4-8 legend
Call-out
Number
Description
1 Gas connection tube
2 O2E electrical connecting cable
3 Air intake filter
4 Oxygen hose connection
