Unpacking and Accessories
11-2 User Manual
DMR V4C 3.3 (User Manual) V-4 06-May-2022
Table11-1.Parts and accessories provided with the V4C-O2E Oxygen Mixer
Item
Description
Catalogue Number
1 x V4C-O2E Oxygen Mixer Enhances FiO
2
range of compatible
ventilators.
V4C-O2E
2 x Side arms Used to secure the ventilator to the
Oxygen Mixer.
1 x Handle Used to secure the ventilator to the
Oxygen Mixer and to allow the system
to be carried.
6 x M6 washers
Used to secure the ventilator to the
Oxygen Mixer.
INSTKIT24O2E
6 x M6 screws
1 x M6 allen key
4 x Ventilator adhesive feet Provided in the event that the compati-
ble ventilator is missing its rubber feet.
See Section 4.1, Installation and Assem-
bly for installation instructions.
1 x Alcohol swab Provided to clean surface before install-
ing ventilator rubber feet. See section
4.1, Installation and Assemblyfor instal-
lation instructions.
N/A
1 x Electrical connecting cable Electrical connection between the
Oxygen Mixer and the compatible ven-
tilator
CW03PVGYO2ECBL
1 x Air intake filter (pre-installed) Filters gas entering through the Oxygen
Mixer's air intake.
HW01XXXXFMINT
8 x Replacement air intake filters Replacement filters for the Oxygen
Mixer's air intake.
1 x Gas connection tubing Delivers gas from the Oxygen Mixer to
the compatible ventilator.
TUB0018
1 x Gas connection tubing adapter Male-to-male conical adapter used to
connect the gas transfer tubing to com-
patible ventilators.
1969000
1 x Instructions for Use (English/French) USB Key containing the User's Manual. QMSDMR01436-USB
1 x Quick start guide (English/French) A hardcopy of operation instructions of
the V4C-O2E Oxygen Mixer.
QMSDMR01436-HC
1 x Oxygen hose (DISS - commonly used
in Canada)
Used to connect the oxygen source to
the V4C-O2E Oxygen Mixer. This hose is
made for use with medical oxygen. The
connection is a DISS CGA 1240 connec-
tor for use in Canada.
HS-10IO-DHDFC4
