12-1
DMR V4C 3.3 (User Manual) V-4 06-May-2022
12 Electromagnetic Emissions and Immunity
* The system is a Class II electrical device, therefore the tests were performed between Line and
Neutral only.
Table12-1.Electromagnetic emissions
The ventilator and Oxygen Mixer are intended for use in the electromagnetic environment specified below. The cus-
tomer or the user of the system should ensure that it is used in such an environment.
Phenomenon and standard
Compliance
Electromagnetic Environment -
Guidance
Power Line Conducted Emissions
CISPR 11
Group 1
Class B
The ventilator uses RF energy only for its
internal functions. Therefore, its RF
emissions are very low and are not likely
to cause any interference in nearby
electronic equipment.
Radiated RF Emissions
CISPR 11
Harmonic Emissions
IEC 60601-1-2 / IEC 61000-3-2
Class A
The ventilator is suitable for use in all
establishments including domestic
establishments and those directly con-
nected to the public low-voltage power
supply network that supplies buildings
used for domestic purposes.
Voltage Fluctuations and Flicker Emis-
sions
IEC 60601-1-2 / IEC 61000-3-3
Complies
Table12-2.Electromagnetic immunity
Phenomenon
Basic EMC Standard /
Test Method
Immunity Test Levels for Home
Healthcare Environment
Electrostatic Discharge IEC 60601-1-2 / IEC 61000-4-2 ± 8kV Contact; ±15 kV Air
Electrical Fast Transients/Bursts*
IEC 60601-1-2 / IEC 61000-4-4
±2 kV for power supply lines (mains)
±1 kV for input/output lines
100 kHz pulse repetition frequency
Surge Immunity* IEC 60601-1-2 / IEC 61000-4-5 ± 1 kV line-to-line
Rated Power Frequency Magnetic Field IEC 60601-1-2 / IEC 61000-4-8 30 A/m (60Hz)
Voltage Dips
IEC 60601-1-2 / IEC 61000-4-11
0% during 0.5 cycle
0% during 1 cycle
70% during 30 cycles
Voltage Interruptions 0% during 300 cycles
NOTE: UT is the AC mains voltage prior to application of the test level
