DS-SERIES OWNER’S MANUAL
INTRODUCTION TO THE DATA SWITCH (DS) SERIES
3
PROGRAMMABLE FEATURES OF THE DS MODULES
(con’t)
FEATURE DESCRIPTION ACTION PAGE
NO.
DS71-MD2 HOST MODULE
Rings to
Answer(*)
The number of times the modem rings
before it automatically answers.
Default = 2 rings
Enter number of rings to
auto answer
44
Modem to
Modem
Xon/Xoff(*)
ASCII character used to stop or start
transmission of data.
Default = Disabled
Enable/ Disable Modem to
Modem
44
Connectivity
Timeout(*)
Configures the amount of connectivity
(5 to 255 minutes) before modem
disconnects. Default = 60 minutes
Enter timeout in minutes.
Enter 0 to disable
45
Escape
Character(*)
Allows ASCII characters to be
interpreted as commands instead of data.
Default = 43 (+)
Enter the character you wish
to use as an escape
46
Unit ID
Unique ID for DS-Series unit.
Default = DS71 or DS71-MD2
Enter unit ID 47
DS74 PERIPHERAL I/O MODULE
Serial Port
Configuration
Sets serial port speed for each I/O port
on the DS74. Default = 9600, 8, 1, N,
Xon/Xoff Disabled, RTS/DTR Low
Enter baud rate, data bits,
stop bits, parity, Xon/Xoff,
and DTR/RTS line driver
50
Port Device
Name
Unique ID for each I/O port as displayed
on the main menu. Default = Device A,
Device B, Device C, Device D, etc.
Enter port device name 50
Table 1 (con’t)

BayTech DS6 Specifications

General

Brand	BayTech
Model	DS6
Category	Switch
Language	English
