BCN3D Sigma - Printer Information and Policies; BCN3 D Sigma Component Diagram

Diagram of BCN3D Sigma
1 Teflon tube
2 Extruder
3 Hot-end cable
4 Spool mount
5 Hot-end
6 Purge chamber
7 Printing surface
8 SD reader
9 Touchscreen
10 Filament input hole
11 Plastic Spool
12 Switch
13 Platform
14 Power supply socket
15 USB port
2
3
5
6
7
8
9
10
11
1
4
36 User Manual
