MODELS 852 / 853
These “pusher” models, designed and geared to drive mowers and
other front-mounted attachments, may be converted into a tractor by
swinging the control handles around as illustrated on page 32.
Of the very latest design, they have both high speed and PTO / reverse
safety lockout devices that function when needed, and require no dis-
assembly or deactivation.
A differential lever on the right handlebar has two-wheel drive and dif-
ferential drive settings.
In differential drive, applying just one wheel brake aids in turning to that
side.
Whether in the front-drive or rear-drive mode, the unit will drive forward
when placed in any gear on the gear selector.
With the reverser lever pulled and left against the handlebar, and gear
position #1, #2 or #3 selected, the unit will back up.
Too fast to use when backing the unit, gear position #4 is blocked by
the high speed lockout. 852 model has the fourth speed in pusher
mode; 853 has the fourth speed in tractor mode.
17
RED
REVERSER
LEVER
RIGHT BRAKE
LEVER
DIFFERENTIAL
LEVER
THROTTLE
LEVER
CONTROL COLUMN INDEXING LEVER
ENGINE
TRANSPORT SULKY /
UTILITY TRAILER HITCH
P.T.O.
CLUTCH LEVER
RED
ENGINE
STOP
LEVER
LEVER
LATCH
LEFT
BRAKE
LEVER
GEAR ROD
P.T.O.
CONTROL
ROD
HANDLEBAR
HEIGHT
ADJUSTMENT
LEVER
