ADDENDUM -
SCHEMATICS
(Continued)
SIZE:
DRAWN BY:
TITLE: BESAM MP VER. 6.3,4 DUAL, LO21B/U
PASSPORT PLUS / PARALLAX 2,
Q-DISCONNECT ON SAFETY SIDE
A
100 ENTERPRISE DRIVE
PITTSBURGH, PA 15275
PHONE: (412) 249-4100
FAX: (412) 249-4101
EMAIL: www.beasensors.com
REV BY:
KJG KJG
80.0043.07
SCALE: DATE:
NONE 4 JULY 2005
PART NO:
SHEET
1 OF 1
NOTES: 1) DO NOT POWER ALL SENSORS FROM MASTER CONTROL BOX. POWER SOME OF THE SENSORS OFF OF THE
SLAVE CONTROL.
2) ON BOTH CONTROLS SET PMD FUNCTIONS F20 = b, F19 = b, F18 = 00, F17=00, F16 = 05, F14 = a, F13 = a, F11 = 65
DEGREES.
3) ON THE MASTER CONTROL SET FUNCTION F12 TO 3 DEGREES LESS THAN F10.
4) THE WIRING OF THE SUPERSCANS IS USING THE QUICK DISCONNECT CABLES WITH PREWIRED CONNECTOR
ON SAFETY SIDE.
5) CONFIRM ALL SYNC LINES ARE PRESENT. ADDING SYNC LINES MAY BE REQUIRED.
6) DIPSWITCHES 1 THRU 5 LOCKOUT TIME. 6 (UP/OFF), 7 (UP/OFF), 8 (DOWN/ON).
YELLOW
VIOLET
RED/WHITE
GRAY
WHITE
BLACK
RED
19 + 18 VDC
14 SWITCH 2
BLUE
GREEN
4 COM
3 I IMP
9 MAT LOGIC
18 - 24VDC
17 + 24VDC
8 OFF
12 SYNC
11 O VDC
10 SYNC
3 I IMP
9 MAT LOGIC
13 SWITCH 1
5 P DET
2 P IMP
13 SWITCH 1
5 P DET
2 P IMP
YELLOW
BLUE
BROWN
BLACK
RED
GREEN
WHITE
ORANGE
SUPERSCAN QUICK
DISCONNECT CABLE
ORANGE
BROWN
( See note 6)
8 OFF
AUTO
OFF
HOLD OPEN
N.C. 5
N.O. 4
green
COM 3
white
POWER 2
black
POWER 1
red
18 - 24VDC
17 +24VDC
RED
GREEN
LO21B/U DEFAULT DIP SWITCHES
BESAM MP
OFF
ON
LO21B/U
EMPTY 1
INHIBIT GND 2
INHIBIT + 3
N.C. 4
N.O. 5
COM 6
POWER 7
POWER 8
LEFT APPRCH SIDE SSCAN
EMPTY 1
INHIBIT GND 2
INHIBIT + 3
N.C. 4
N.O. 5
COM 6
POWER 7
POWER 8
LEFT SAFETY SIDE SSCAN
EMPTY 1
INHIBIT GND 2
INHIBIT + 3
N.C. 4
N.O. 5
COM 6
POWER 7
POWER 8
RIGHT APPRCH SIDE SSCAN
EMPTY 1
INHIBIT GND 2
INHIBIT + 3
N.C. 4
N.O. 5
COM 6
POWER 7
POWER 8
RIGHT SAFETY SIDE SSCAN
