BeaconMedaes MEGA 2 - Page 44

44
Part No. 6-847684-00 Rev. D01
Testing
Figure 26: Power Supply Output Testing
Figure 27: Power Supply AC Input Testing
Three-wire harness
from power supply
Black (gnd)
Orange (+5)
Red (+24)
Annunciator Module
Line (black)
Neutral (white)
Power Supply Assembly
Fuse
Holder
