13
Part No. 6-847684-00 Rev. D01
Wiring Schematics Alarm Wiring Examples
Wiring Installation
The wiring schematics listed below are
provided. Call BeaconMedæs at 1-888-
4MEDGAS (1-888-463-3427), for technical
support .
1. Power Supply Module
2. Sensor Module to Digital Display
Module
3. Multi-Signal Module
4. Remote Pressure/Vacuum
Transmission
5. Multi-Signal Module Relays
6. General Fault/Auxiliary Relays
7. Digital Display Module High/Low Relays
8. Remote Pressure/Vacuum Switches
9. Johnson Controls METASYS®
Wiring examples of master/area alarms for
the following systems are provided:
1. Two master alarm panels with digital
displays - high-pressure manifold/no
reserve (oxygen shown) - Pg. 22.
2. Two master alarm panels with digital
displays - liquid manifold/high-pressure
reserve (oxygen shown) - Pg. 23.
3. Two master alarm panels with digital
displays - liquid bulk/liquid reserve
(oxygen shown) - Pg. 24.
4. Two multi-signal master alarm panels -
duplex air compressor and vacuum
pump systems - Pg. 25.
5. Area alarm panel - gas services for
oxygen, medical air, and vacuum - Pg.
26.
