Part No. 6-847684-00 Rev. D01
Introduction
Alarm Configuration
Example: P/N 6-M2R-OAVB
Example: P/N 6-M2R-OXAVNWMM
Unpacking
1. Remove alarm panel back box from
shipping carton. Do not remove alarm
front panel (wrapped in anti-static
shipping bag).
2. If alarm panel is configured with
remote sensors, remove sensor
rough-in and mounting box from small
individual boxes shipped within main
alarm panel shipping carton.
3. Store all other components not
removed in steps 1 and 2 inside
shipping carton in a safe place for
installation later.
4. Install back box and sensor rough-in
as described in this manual.
