BeaconMedaes MEGA 2 - Field Installation Kits

53
Part No. 6-847684-00 Rev. D01
ITEM PART NUMBER DESCRIPTION
8 Digital Sensor
- 6-232460-00 Oxygen
- 6-232461-00 Nitrous Oxide
- 6-232462-00 Medical Air
- 6-232463-00 Vacuum
- 6-232464-00 Nitrogen
- 6-232465-00 Helium
- 6-232466-00 Lab Air
- 6-232467-00 Lab Vacuum
- 6-232468-00 Instrument Air
- 6-232469-00 WAGD
- 6-232470-00 Carbon Dioxide
- 6-232471-00 CO2/O2
- 6-232472-00 O2/CO2
- 6-232473-00 He/O2
- 6-232474-00 O2/He
- 6-232476-00 Air (ISO)
- 6-232477-00 Vacuum (ISO)
- 6-232478-00 O2 (100 PSI)
- 6-232479-00 Air (100 PSI)
- 6-232480-00 CO2 (100 PSI)
9 Console Rough-In
- 6-233010-00 Oxygen
O2 (100 PSI)
- 6-233011-00 Nitrous Oxide
- 6-233012-00 Medical Air
Air (100 PSI)
Lab Air
- 6-233013-00 Vacuum
Lab Vacuum
- 6-233014-00 Nitrogen
- 6-233016-00 Air (ISO)
- 6-233017-00 Vacuum (ISO)
- 6-233018-00 Instrument Air
- 6-233019-00 WAGD
- 6-233020-00 Carbon Dioxide
CO2 (100 PSI)
- 6-233021-00 CO2/O2
- 6-233022-00 O2/CO2
- 6-233023-00 He/O2
- 6-233024-00 O2/He
Field Installation Kits
ITEM P
ART NUMBER DESCRIPTION
1 Digital Display Module
- 6-290980-10 Oxygen
- 6-290980-11 Nitrous Oxide
- 6-290980-12 Medical Air
- 6-290980-13 Vacuum
- 6-290980-14 Nitrogen
- 6-290980-16 Air (ISO)
- 6-290980-17 Vacuum (ISO)
- 6-290980-18 Instrument Air
- 6-290980-19 WAGD
- 6-290980-20 Carbon Dioxide
- 6-290980-21 CO2/O2
- 6-290980-22 O2/CO2
- 6-290980-23 He/O2
- 6-290980-24 O2/He
- 6-290980-25 Helium
- 6-290980-26 Lab Air
- 6-290980-27 Lab Vacuum
- 6-290980-28 O2 (100 PSI)
- 6-290980-29 Air (100 PSI)
- 6-290980-30 CO2 (100 PSI)
2 Multi-Signal Module
- 6-290981-00 W/O Relays
- 6-290981-RL W/ Relays
Field installation kits include everything required to
replace a blank module with a digital display mod-
ule or a multi-signal module. Digital display module
kits include sensors.
NOTE:
Before ordering replacement sensor, determine
whether faulty sensor is analog or digital type by
part number listed on sensor label.
Faulty sensors must be replaced with same type.
