Technical data
Dimensions of the housing (W x H x D) 155 x 130 x 50 mm
Housing material PC
Degree of protection IP54, only for installation indoors
Supply voltage 230 V / 50 Hz (connection type Y)
Input power 6 V A
Fuse 2 A slow-blow
Drive switching capacity 1 drive 230 V / 50 Hz maximum 260 V A
Light switching capacity 230 V / 50 Hz maximum 100 W
Control voltage 24 V maximum 100 mA
Temperature range -10°C to +50°C
Radio frequency 868.3 MHz
