5.5.3.3 Input data
Index 6000 SSI Inputs
Index (hex) Name Meaning Data type Flags Default
6000:0 SSI Inputs Length of this object UINT8 RO 0x12 (18
dec
)
6000:01 Data error SSI input error:
- SSI without power supply
- Broken wire at SSI data inputs D+ or D-
- Data cables interchanged
If no data communication takes place the SSI input of
the terminal is on low level.
BOOLEAN RO 0x00 (0
dec
)
6000:02 Frame error There is an incorrect data frame, i.e. the data frame
was not concluded with zero
(possibly wire breakage in the clock lines)
BOOLEAN RO 0x00 (0
dec
)
6000:03 Power failure A encoder-specific error has occurred. This error bit
is only displayed if it was activated beforehand by in-
dex 0x8000:02 [}137].
BOOLEAN RO 0x00 (0
dec
)
6000:0E Sync Error The Sync error bit is only required for DC mode. It in-
dicates whether a synchronization error has occurred
during the previous cycle.
This means a SYNC signal was triggered in the
EL500x, although no new process data were avail-
able (0=OK, 1=NOK).
BOOLEAN RO 0x00 (0
dec
)
6000:0F TxPDO State Validity of the data of the associated TxPDO (0 =
valid, 1 = invalid).
BOOLEAN RO 0x00 (0
dec
)
6000:10 TxPDO Toggle The TxPDO toggle is toggled by the slave when the
data of the associated TxPDO is updated.
BOOLEAN RO 0x00 (0
dec
)
6000:11 Counter value Counter value UINT32 RO 0x000000000000
0000(0
dec
)
6000:12 Timestamp Timestamp for the last detected counter value UINT64 RO
5.5.3.4 Objects for diagnosis
Index A000 SSI Diag data
Index (hex) Name Meaning Data type Flags Default
A000:0 SSI Diag data Length of this object UINT8 RO 0x01 (1
dec
)
A000:01 Detected SSI-frame
size
Size of the SSI frame that the terminal has detected UINT8 RO 0x00 (0
dec
)
5.5.3.5 Standard objects
Index 1000 Device type
Index (hex) Name Meaning Data type Flags Default
1000:0 Device type Device type of the EtherCAT slave: the Lo-Word con-
tains the CoE profile used (5001). The Hi-Word con-
tains the module profile according to the modular de-
vice profile.
UINT32 RO 0x01F51389
(32838537
dec
)
Index 1008 Device name
Index (hex) Name Meaning Data type Flags Default
1008:0 Device name Device name of the EtherCAT slave STRING RO EL5001-0011
Index 1009 Hardware version
Index (hex) Name Meaning Data type Flags Default
1009:0 Hardware version Hardware version of the EtherCAT slave STRING RO -
