Commissioning
EL500x 153Version: 3.6
Index 6010 TSC Slave Frame Elements
Index (hex) Name Meaning Data type Flags Default
6010:0 TSC Slave Frame El-
ements
Max. Subindex UINT8 RO 0x04 (4
dec
)
6010:01 TSC__Slave Cmd reserved UINT8 RO 0x00 (0
dec
)
6010:02 TSC__Slave ConnID reserved UINT16 RO 0x0000 (0
dec
)
6010:03 TSC__Slave CRC_0 reserved UINT16 RO 0x0000 (0
dec
)
6010:04 TSC__Slave CRC_1 reserved UINT16 RO 0x0000 (0
dec
)
Index 7010 TSC Master Frame Elements
Index (hex) Name Meaning Data type Flags Default
7010:0 TSC Master Frame
Elements
Maximaler Subindex UINT8 RO 0x03 (3
dec
)
7010:01 TSC__Master Cmd reserved UINT8 RO 0x00 (0
dec
)
7010:02 TSC__Master ConnID reserved UINT16 RO 0x0000 (0
dec
)
7010:03 TSC__Master CRC_0 reserved UINT16 RO 0x0000 (0
dec
)
Index 8010 TSC Settings
Index (hex) Name Meaning Data type Flags Default
8010:0 TSC Settings Max. Subindex UINT8 RO 0x02 (2
dec
)
8010:01 Address TwinSAFE SC Address UINT16 RO 0x0000 (0
dec
)
8010:02 Connection Mode Selection of the TwinSAFE SC CRC UINT32 RO 0x00000000 (0
dec
)
97039
dec
TwinSAFE SC CRC1 master
153375
dec
TwinSAFE SC CRC2 master
20469
dec
TwinSAFE SC CRC3 master
283633
dec
TwinSAFE SC CRC4 master
389589
dec
TwinSAFE SC CRC5 master
419387
dec
TwinSAFE SC CRC6 master
506061
dec
TwinSAFE SC CRC7 master
582077
dec
TwinSAFE SC CRC8 master
