Product overview
EL9xxx18 Version: 3.9
The EL9080 separation terminal interrupts the power contacts within a bus terminal block. The terminal
enables operation with different voltages on the separated sides of the power contacts. But the K-Bus is
looped through. The discontinuance of the Power Contacts is especially displayed by the orange front plate
of the EL9080. The EL9080 separation terminal does not have any other function or connection facility.
Technical Data EL9011 EL9012 EL9080
Electrical isolation - 500V (E-bus/field
potential)
Bit width in the process image 0
Configuration no address or configuration settings
Diagnosis -
PE contact no
Renewed infeed -
Connection facility to additional
power contact
-
Side by side mounting on Bus
Terminals with power contact
yes
Side by side mounting on Bus
Terminals without power contact
yes
Electrical connection to mounting
rail
no
Weight approx. 8 g approx. 10 g approx. 40 g
Permissible ambient temperature -25°C ... +60°C (extended temperature range)
Permissible ambient temperature
range (during storage)
-40°C ... +85°C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 8 mm x 100
mm x 34 mm
(width aligned: 5 mm)
approx. 8 mm x 100
mm x 55 mm (width
aligned: 5 mm)
approx.15 mm x 100
mm x 70 mm
(width aligned: 12 mm)
Mounting [}73]
aligned to the last terminal in the terminal block on 35 mm mounting rail
conforms to EN 60715
Vibration/shock resistance conforms to EN 60068-2-6/EN 60068-2-27
EMC resistance burst/ESD conforms to EN 61000-6-2/EN 61000-6-4
Protect. class IP 20
Installation pos. variable
Approval CE
ATEX [}85]
cULus [}86]
