3.5 EL9180
3.5.1 EL9180 - Introduction and Technical Data
Fig.22: EL9080
The EL9180 allows the supply voltage to be accessed a number of times via spring force terminals. The
EtherCAT Terminal makes it unnecessary to use additional terminal blocks on the terminal strip.
