Product overview
EL9xxx 29Version: 3.9
Technical data
Technical data EL9180
Technology potential distribution terminal
Power contact current load ≤ 10 A
Power LED -
Defect LED -
Current consumption from E-Bus -
Nominal voltage arbitrary up to 230 V AC/DC
Integrated fine-wire fuse -
Electrical isolation 500 V (E-bus/field potential)
Diagnosis -
Reported to E-bus -
Power contact 3 x power contact
PE contact yes
Shield connection -
Renewed infeed -
Connection facility to additional power contact 2
Side by side mounting on Bus Terminals with power
contact
yes
Side by side mounting on Bus Terminals without power
contact
-
Electrical connection to mounting rail yes
Bit width in the process image -
Configuration no address or configuration settings
Weight approx. 50 g
Permissible ambient temperature range (during opera-
tion)
0°C ... +55°C
Permissible ambient temperature range (during stor-
age)
-25°C ... +85°C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 15 mm x 100 mm x 70 mm (width aligned: 12 mm)
Mounting [}73]
on 35 mm mounting rail conform to EN 60715
Vibration/shock resistance conforms to EN60068-2-6/EN60068-2-27,
see Installation instructions [}76] for enhanced mechanical load capacity
EMC resistance burst/ESD conforms to EN 61000-6-2/EN 61000-6-4
Protect. class IP 20
Installation pos.
variable, see chapter "Mounting of Passive Terminals [}83]"
Approval CE
ATEX [}84]
cULus [}86]
