Product overview
EL9xxx 17Version: 3.9
3 Product overview
3.1 EL9011, EL9012, EL9080
3.1.1 EL9011, EL9012, EL9080 - Introduction and Technical Data
Fig.12: EL9011
Each EtherCAT terminal block must be terminated at the right hand end with a EL9011 bus end cap due to
mechanical and electrical protection.
Fig.13: EL9080
