Product overview
EL9xxx20 Version: 3.9
Technical data
Technical Data EL9070
Technology shield terminal
Current load ≤ 10 A
Power LED -
Error LED -
Current consumption E-bus -
Nominal voltage arbitrary up to 230 V AC
Integrated fine-wire fuse -
Electrical isolation 500V (E-bus/field potential)
Diagnostics in the process image -
Reported to E-bus -
PE contact no
Shield connection 8 x
E-bus looped through yes
Bit width in the process image 0
Electrical connection to mounting rail yes (dissipation of EMC interference via large copper surfaces on the mount-
ing rail)
Electrical connection to power contacts -
Renewed infeed -
Connection facility to additional power contact no
Side by side mounting on Bus Terminals with power con-
tact
yes, left side without PE
Side by side mounting on Bus Terminals without power
contact
-
Configuration no address or configuration settings
Dimensions (W x H x D) approx. 15 mm x 100 mm x 70 mm (width aligned: 12 mm)
Weight approx. 50 g
Permissible ambient temperature range (during opera-
tion)
0°C ... +55°C
Permissible ambient temperature range (during storage) -25°C ... +85°C
Permissible relative humidity 95%, no condensation
Mounting [}73]
on 35 mm mounting rail conforms to EN 60715
Vibration/shock resistance conforms to EN 60068-2-6/EN 60068-2-27
EMC resistance burst/ESD conforms to EN 61000-6-2/EN 61000-6-4
Protect. class IP 20
Installation pos.
variable, see chapter "Mounting of Passive Terminals [}83]"
Approval CE
cULus [}86]
Connection
Terminal point Meaning
Indication No.
1 - 8 1 - 8 Terminal points 1 - 8 are connected internally
