Beckhoff EL9 Series User Manual

Product overview
EL9xxx26 Version: 3.9
Technical data
Technical data EL9150 EL9160
Nominal voltage 230 V
AC
(120 V
AC
)
Power contact current load max. 10 A
Electrical isolation 500V (E-bus/field potential)
Current consumption from E-Bus - typ. 90 mA
Bit width in the process image - 1 bit (diagnosis)
Configuration no address or configuration settings
Power LED yes
Diagnosis no yes, in process image
Electrical connection to mounting rail no
PE contact no
Renewed infeed yes
Connection facility to additional power
contact
1
Side by side mounting on Bus Termi-
nals with power contact
yes
Side by side mounting on Bus Termi-
nals without power contact
yes
Weight approx. 50 g
Permissible ambient temperature
range (during operation)
0°C ... +55°C
Permissible ambient temperature
range (during storage)
-25°C ... +85°C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 15 mm x 100 mm x 70 mm (width aligned: 12 mm)
Mounting [}73]
on 35 mm mounting rail conforms to EN 60715
Vibration/shock resistance conforms to EN 60068-2-6/EN 60068-2-27
EMC resistance burst/ESD conforms to EN 61000-6-2/EN 61000-6-4
Protect. class IP 20
Installation pos.
variable, see chapter "Mounting of Passive Ter-
minals [}83]"
variable
Approval CE
cULus [}86]
Connection EL9150
CAUTION
Hazard to individuals and devices!
When designing a Bus Terminal block with different potentials on the power contacts (e.g. 230 V AC and 24
V DC), please note that it is mandatory to use potential separation terminals (EL9080)!
Bring the bus system into a safe, powered down state before starting installation, disassembly or wiring of
the Bus Terminals!
Terminal point Description
Indication No.
1 not used
230 V
AC
(120 V
AC
) 2 Supply input 230 V
AC
(120 V
AC
), connected internally with terminal 6 and
power contact)
0 V 3 0 V for supply input (connected internally with terminal 7 and power contact)
PE 4 PE (connected internally with terminal 8 and PE power contact)
5 not used
230 V
AC
(120 V
AC
) 6 Supply input 230 V
AC
(120 V
AC
), (connected internally with terminal 2 and
power contact)
0 V 7 0 V for supply input (connected internally with terminal 3 and power contact)
PE 8 PE (connected internally with terminal 4 and PE power contact)
