Beckhoff EL9 Series User Manual

Product overview
EL9xxx36 Version: 3.9
Technical data
Technical Data EL9185
Nominal voltage arbitrary up to 230 V AC/DC
Current load ≤ 10 A
Diagnosis -
Message to E-Bus -
PE contact no
Shield connection -
Current consumption from E-Bus -
Bit width in the process image 0
Electrical connection to mounting
rail
-
Electrical isolation 500 V (E-bus/field potential)
Renewed infeed -
Side by side mounting on EtherCAT
Terminals with power contact
only 2 power contacts, no PE
Side by side mounting on EtherCAT
Terminals without power contact
-
Connection facility to additional
power contact
4
Configuration no address or configuration settings
Weight approx. 65 g
Permissible ambient temperature
range (during operation)
-25°C ... +60°C (extended temperature range)
Permissible ambient temperature
range (during storage)
-40°C ... +85°C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 15 mm x 100 mm x 70 mm (width aligned: 12 mm)
Mounting [}73]
on 35 mm mounting rail conforms to EN 60715
Vibration/shock resistance
conforms to EN60068-2-6/EN60068-2-27, see Installation
instructions [}76] for enhanced mechanical load capacity
EMC resistance burst/ESD conforms to EN 61000-6-2/EN 61000-6-4
Protect. class IP 20
Installation pos.
variable, see chapter "Mounting of Passive Terminals [}83]"
Approval CE
ATEX [}85]
cULus [}86]
Connection EL9185
Terminal point Description
Indication No.
Output 1, 2 ,5, 6 1, 2 ,5, 6 Output 1, 2 ,5, 6
(internally connected with positive power contact)
Output 3, 4, 7, 8 3, 4, 7, 8 Output 3, 4, 7, 8
(internally connected with negative power contact)
