Product overview
EL9xxx38 Version: 3.9
Technical data
Technical Data EL9185-0010
Nominal voltage arbitrary up to 230 V AC/DC
Current load ≤ 10 A
Diagnosis -
Message to E-Bus -
PE contact no
Shield connection -
Current consumption from E-Bus -
Bit width in the process image 0
Electrical connection to mounting
rail
-
Electrical isolation 500 V (E-bus/field potential)
Renewed infeed yes
Side by side mounting on EtherCAT
Terminals with power contact
yes
Side by side mounting on EtherCAT
Terminals without power contact
yes
Connection facility to additional
power contact
3
Configuration no address or configuration settings
Weight approx. 65 g
Permissible ambient temperature
range (during operation)
-25°C ... +60°C (extended temperature range)
Permissible ambient temperature
range (during storage)
-40°C ... +85°C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 15 mm x 100 mm x 70 mm (width aligned: 12 mm)
Mounting [}73]
on 35 mm mounting rail conforms to EN 60715
Vibration/shock resistance
conforms to EN60068-2-6/EN60068-2-27, see Installation
instructions [}76] for enhanced mechanical load capacity
EMC resistance burst/ESD conforms to EN 61000-6-2/EN 61000-6-4
Protect. class IP 20
Installation pos.
variable, see chapter "Mounting of Passive Terminals [}83]"
Approval CE
Connection EL9185-0010
Terminal point Description
Indication No.
Output 1, 2 ,5, 6 1, 2 ,5, 6 Output 1, 2 ,5, 6
(internally connected with positive power contact, right-sided)
Output 3, 4, 7, 8 3, 4, 7, 8 Output 3, 4, 7, 8
(internally connected with negative power contact, right-
sided)
