Beckhoff EL9 Series User Manual

Product overview
EL9xxx40 Version: 3.9
Technical Data
Technical Data EL9186 EL9187
Nominal voltage ≤ 60 V
DC
Current load ≤ 10 A
Diagnosis -
Message to E-Bus -
PE contact no
Shield connection -
Outputs 8 (connected with positive power contact) 8 x 0 V contact (connected with negative
power contact)
Current consumption from E-Bus -
Bit width in the process image 0
Electrical connection to mounting rail -
Electrical isolation 500 V (E-bus/field potential)
Renewed power feed -
Side by side mounting on EtherCAT Termi-
nals with power contact
yes, left side without PE
Side by side mounting on EtherCAT Termi-
nals without power contact
-
Connection facility to additional power con-
tact
8
Configuration no address or configuration settings
Weight approx. 65 g
Permissible ambient temperature range (dur-
ing operation)
-25°C ... +60°C (extended temperature range)
Permissible ambient temperature range (dur-
ing storage)
-40°C ... +85°C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 15 mm x 100 mm x 70 mm (width aligned: 12 mm)
Mounting [}73]
on 35 mm mounting rail conforms to EN 60715
Vibration/shock resistance
conforms to EN60068-2-6/EN60068-2-27, see Installation instructions [}76] for en-
hanced mechanical load capacity
EMC resistance burst/ESD conforms to EN 61000-6-2/EN 61000-6-4
Protect. class IP 20
Installation pos.
variable, see chapter "Mounting of Passive Terminals [}83]"
Approval CE
ATEX [}85]
cULus [}86]
Connection EL9186
Terminal point Description
Indication No.
Output 1 - 8 1 - 8 Output 1 - 8 (internally connected with positive power
contact)
Connection EL9187
Terminal point Description
Indication No.
Output 1 - 8 1 - 8 Output 1 - 8 (internally connected with negative power
contact)
