Technical data EL9195
Technology shield terminal, for dissipation of EMC interference
Power contact current load max. 10 A
Power LED -
Defect LED -
Current consumption from E-Bus -
Nominal voltage arbitrary up to 230 V AC/DC
Integrated fine-wire fuse -
Electrical isolation 500 V (E-bus/field potential)
Diagnosis -
Reported to E-bus -
Power contact 2 x power contact
PE contact -
Renewed infeed -
Connection facility to additional power con-
tact
2
Side by side mounting on Bus Terminals with
power contact
only 2 power contacts
Side by side mounting on Bus Terminals
without power contact
-
Shield connection 2 x
Electrical connection to mounting rail yes
Bit width in the process image -
Configuration no address or configuration settings
Weight approx. 50 g
Permissible ambient temperature range (dur-
ing operation)
0°C ... +55°C
Permissible ambient temperature range (dur-
ing storage)
-25°C ... +85°C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 15 mm x 100 mm x 70 mm (width aligned: 12 mm)
Mounting [}73]
on 35 mm mounting rail conform to EN 60715
Vibration/shock resistance conforms to EN 60068-2-6/EN 60068-2-27
EMC resistance burst/ESD conforms to EN 61000-6-2/EN 61000-6-4
Protect. class IP 20
Installation pos.
variable, see chapter "Mounting of Passive Terminals [}83]"
Approval CE
ATEX [}84]
cULus [}86]
Connection EL9195
CAUTION
Hazard to individuals and devices!
When designing a Bus Terminal block with different potentials on the power contacts (e.g. 230 V AC and 24
V DC), please note that it is mandatory to use potential separation terminals (EL9080)!
Bring the bus system into a safe, powered down state before starting installation, disassembly or wiring of
the Bus Terminals!
