Product overview
EL9xxx 53Version: 3.9
Technical data
Technical data EL9250 EL9260
Nominal voltage 230 V AC
Power contact current load max. 10 A
Electrical isolation 500 V (E-bus/field potential)
Integrated fine-wire fuse yes; 6.3 A
Current consumption from E-Bus - typ. 90 mA
Bit width in the process image - 2 bit (diagnosis)
Configuration no address or configuration settings
Power LED yes
Diagnosis (fuse) yes, Error LED yes, in process image and Error LED
Electrical connection to mounting rail no
PE contact yes
Renewed infeed yes
Connection facility to additional power con-
tact
1
Side by side mounting on Bus Terminals with
power contact
yes
Side by side mounting on Bus Terminals
without power contact
yes
Weight approx. 55 g
Permissible ambient temperature range (dur-
ing operation)
0°C ... +55°C
Permissible ambient temperature range (dur-
ing storage)
-25°C ... +85°C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 15 mm x 100 mm x 70 mm (width aligned: 12 mm)
Mounting [}73]
on 35 mm mounting rail conforms to EN 60715
Vibration/shock resistance conforms to EN 60068-2-6/EN 60068-2-27
EMC resistance burst/ESD conforms to EN 61000-6-2/EN 61000-6-4
Protect. class IP 20
Installation pos.
variable, see chapter "Mounting of Passive
Terminals [}83]"
variable
Approval CE
Connection EL9250, EL9260
CAUTION
Hazard to individuals and devices!
When designing a Bus Terminal block with different potentials on the power contacts (e.g. 230 V AC and 24
V DC), please note that it is mandatory to use potential separation terminals (EL9080)!
Bring the bus system into a safe, powered down state before starting installation, disassembly or wiring of
the Bus Terminals!
Terminal point Description
Indication No.
230 V AC 1 Supply input 230 V AC;
connected internally with terminal 4 and 230 V AC power contact)
N 2 N for supply input;
connected internally with terminal 5 and neutral power contact)
PE 3 PE;
connected internally with terminal 6 and PE power contact)
230 V AC 4 Supply input 230 V AC;
connected internally with terminal 1 and 230 V AC power contact)
N 5 N for supply input;
connected internally with terminal 2 and neutral power contact)
PE 6 PE;
connected internally with terminal 3 and PE power contact)
