Product overview
EL9xxx 59Version: 3.9
The EL9540 system terminal contains an overvoltage filter for the 24 V field supply, the EL9550 for the 24 V
field and system supply. The filter protects the EtherCAT Terminals from line-bound surge voltages that can
occur due to high-energy, dynamic disturbances such as switching overvoltages at inductive consumers or
indirect lightning strikes at the supply lines.
In the EL9550-0012 variant, the current load is 10 A for both the field supply and the system supply. The
higher system supply is advantageous for the supply of Embedded PCs that have a higher current
consumption.
The EtherCAT Terminals EL9540 or EL9550 protect the terminal station from damage in particularly harsh
environments. The ship classification organisations require the use in shipbuilding applications and in the
onshore/offshore sector.
Technical data
Technical data EL9540 EL9550 EL9550-0012
Function surge filter field supply surge filter system and field supply
Nominal voltage 24 V (-15 %/+20 %)
Surge filter field supply yes
Surge filter system supply - yes
Rated current
field supply
≤ 10 A
Rated current
system supply
- ≤ 1.5 A (from hardware version
03)
≤ 10 A
Diagnostics -
Reported to E-Bus -
PE contact yes -
Shield connection -
Current consumption E-bus -
Bit width in the process image 0
Connection to mounting rail -
Electrical isolation 500 V (E-bus/field potential)
Renewed infeed yes
Connection facility to additional
power contact
2 1
Side by side mounting on Ether-
CAT Terminals with power con-
tact
yes -
Side by side mounting on Ether-
CAT Terminals without power
contact
yes
Dimensions (B x H x T) approx. 15 mm x 100 mm x 70 mm (width aligned: 12 mm)
Configuration no address- or configuration setting necessary
Weight approx. 50 g
Permissible ambient tempera-
ture range (during operation)
-25°C ... +60°C (extended temperature range)
Permissible ambient tempera-
ture range (during storage)
-40°C ... +85°C
Permissible relative humidity 95%, no condensation
Mounting [}73]
on 35 mm mounting rail conforms to EN 60715
Vibration/shock resistance
conforms to EN60068-2-6/EN60068-2-27, see Installation instructions [}76] for enhanced mechan-
ical load capacity
EMC resistance burst/ESD conforms to EN 61000-6-2/EN 61000-6-4
Protect. class IP 20
Installation pos.
variable, see chapter "Mounting of Passive Terminals [}83]"
Approval CE
ATEX [}85]
cULus [}86]
CE
ATEX [}85]
cULus [}86]
IECEx
CE
