Product overview
EL9xxx62 Version: 3.9
Technical data
Technical data EL9570
Technology buffer capacitor
Nominal voltage 50 V
Capacity 500 µF
Ripple current 10 A in continuous operation
Internal resistance < 10 mΩ
Surge voltage protection > 56 V
Recommended ballast resistor 10 Ω, 10 W typ.
Overvoltage control range ±2 V
Ballast resistor clock rate load-dependent, 2-point control
Electrical isolation 1500 V
Diagnostics -
Message to E-Bus -
PE contact no
Shield connection -
Current consumption from E-Bus -
Bit width in the process image 0
Electrical connection to mounting rail -
Electrical isolation -
Renewed infeed -
Connection facility to additional power con-
tact
-
Side by side mounting on EtherCAT Termi-
nals with power contact
yes, left side without PE
Side by side mounting on EtherCAT Termi-
nals without power contact
yes
Configuration no address or configuration settings
Weight approx.. 90 g
Permissible ambient temperature range (dur-
ing operation)
0°C ... +55°C
Permissible ambient temperature range (dur-
ing storage)
-25°C ... +85°C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 15 mm x 100 mm x 70 mm (width aligned: 12 mm)
Mounting [}73]
on 35 mm mounting rail conforms to EN 60715
Vibration/shock resistance conforms to EN 60068-2-6/EN 60068-2-27
EMC resistance burst/ESD conforms to EN 61000-6-2/EN 61000-6-4
Protect. class IP 20
Installation pos.
variable, see chapter "Mounting of Passive Terminals [}83]"
Approval CE
ATEX [}84]
LEDs und Anschlussbelegung EL9570
LED Color Meaning
Overload green off No error
on Overload, energy will be absorbed in the connected
ballast resistor
