Beckhoff KL304 Series Documentation

Access from the user program
KL304x, KL305x34 Version: 4.0
Address Name Default value R/W Storage medium
R0 [}35]
Raw ADC value variable R RAM
R1 to R5 reserved 0x0000 R
R6 [}35]
Diagnostic register variable R RAM
R7 [}35]
Command register - not used 0x0000 R
R8 [}35]
Terminal type e.g.3042 R ROM
R9 [}35]
Software version number 0x???? R ROM
R10 [}35]
Multiplex shift register 0x0218/0130 R ROM
R11 [}35]
Signal channels 0x0218 R ROM
R12 [}35]
Minimum data length 0x0098 R ROM
R13 [}35]
Data structure 0x0000 R ROM
R14 reserved 0x0000 R
R15 [}36]
Alignment register variable R/W RAM
R16 [}36]
Hardware version number 0x???? R/W SEEROM
R17 [}36]
Hardware compensation: Offset specific R/W SEEROM
R18 [}36]
Hardware compensation: Gain specific R/W SEEROM
R19 [}36]
Manufacturer scaling: Offset 0x0000 R/W SEEROM
R20 [}36]
Manufacturer scaling: Gain 0x2002 R/W SEEROM
R21 [}36]
Overrange limit 0x0FFF R/W SEEROM
R22 [}36]
Under range limit 0x0000 R/W SEEROM
R23 [}36]
ADC hardware preset 0x0000 R/W SEEROM
R24 to R30 reserved 0x0000 R/W SEEROM
R31 [}36]
Code word register variable R/W RAM
R32 [}37]
Feature register 0x01106 R/W SEEROM
R33 [}37]
User scaling: Offset 0x0000 R/W SEEROM
R34 [}37]
User scaling: Gain 0x0100 R/W SEEROM
R35 [}37]
Limit value 1 0x0000 R/W SEEROM
R36 [}38]
Limit value 2 0x0000 R/W SEEROM
R37 to R63 reserved 0x0000 R/W SEEROM
