Access from the user program
KL304x, KL305x 37Version: 4.0
Feature bit no. Description of the operation mode
Bit 0 1
User scaling (R33, R34 [}37]) active [0]
Bit 1 1
Manufacturer scaling (R19, R20 [}36]) active [1]
Bit 2 1 Watchdog timer active [1]
In the delivery state, the watchdog timer is switched on.
Bit 3 1 Sign / amount representation [0]
Sign / amount representation is active instead of two's-complement
representation. (-1=0x8001).
Bit 4 1 Siemens output format [0]
This bit is used for inserting status information on the lowest 3 bits (see
below).
Bits 5 to 7 - Reserved, don't change
Bit 8 1 Over range Protection [1]
If values exceed or fall below the limits of the registers OVRL (R21 [}36])
and UNRL (R22 [}36]), the status bits are set and the measuring range is
restricted accordingly.
Bit 9 1 Limit value 1 active [0]
The process data are compared with limit value 1 (R35 [}37]), and
appropriate status bits are set.
Bit 10 1 Limit value 2 active [0]
The process data are compared with limit value 2 (R36 [}38]), and
appropriate status bits are set.
Bit 11 1 Filter1 active [0]
For filter properties, see R37 [}38]
Bits 12 to 15 - Reserved, don't change
If the Siemens output format is selected, the lowest threebits are used for status evaluation. The process
data is represented in bits 15 to 3, with bit15 representing the sign bit. Scaling of the measured value
according to the Siemens standard has to be done via user scaling (R33, R34 [}37]).
KL3041, KL3042 and KL3044
Measured value Bits 15 to 3 Bit 2
X
Bit1
Error
Bit 0
Overflow
Measured value > 20mA 0 0 1
Measured value <20mA Process data 0 0 0
KL3051, KL3052 and KL3054
Measured value Bits 15 to 3 Bit 2
X
Bit1
Error
Bit 0
Overflow
Measured value > 20mA 0 0 1
4mA < measured value
<20mA
Process data 0 0 0
Measured value < 4mA Process data 0 1 1
• R33: User scaling - offset (B_w)
16bit signed integer
This register contains the offset of the user straight-line equation (Eq. 1.4 [}12]). The straight-line
equation is activated via register R32 [}37].
• R34: User scaling - gain (Aw_)
16bit signed integer*2
-8
This register contains the scale factor of the user straight-line equation (Eq. 1.4 [}12]). The straight-line
equation is activated via register R32 [}37].
• R35: Limit value 1 (Y_2)
If the process data are outside this threshold, the appropriate bits are set in the status byte.
