Product overview
24 ─── Version: 1.0XPlanar
3.3.3Power cable
Power is supplied to the tiles via star distributors or T-connectors.
The star distributors are available in the following versions:
ZC2000‑0000‑0018
The 4-way star distributor supplies power to up to four tiles.
Plug: 4xM12, K-coded
5m supply cable
ZC2000‑0000‑0017
The 6-way star distributor supplies power to up to six tiles.
Plug: 6xM12, K-coded
5m supply cable
