Beckhoff XPlanar User Manual

Mechanical Installation – Part 2: Mover
Version: 1.0 ─── 73XPlanar
Permanent magnets can attract tools
The permanent magnets on the underside of the movers are now
exposed and can attract tools used to remove the bumpers.
1
1
2
► Remove two screws[1]
► Remove a bumper[2]
► Remove further bumpers in the same way
2
1
► Place the frame[1] on the work surface with the top side[2] fac-
ing upwards
