8
Miditherm MP
1 Install unit only on adequately stable and non-
combustible surface. • Because of the wax
vapours, install the furnace under a chimney
stalk as far as possible. Always discharge
vapours outdoors. • Only use the furnace in
dry rooms. • There must not be any combustible
objects in the area near the furnace. • There
must not be any highly flammable or explosive gas,
liquids or solid material in the same room as the
furnace.
2 Prior to power connection check whether the
data on the rating plate correspond to the power
supply network. In the case of lack of clarity,
consult a qualified electrician. • Always connect
the furnace to a separate circuit with 16-ampere
fuse protection. • The unit is subject to safety
class I and may only be connected to properly
grounded power sources. • Use the rear plug
only for connecting the Regulus furnace suction
extraction unit (Ref. 25750, 200....240 V). This
also applies to the plug on Miditherm 100 MP /
100....120 V (Ref. 26151)!
If moulds are to be preheated using the shock
heat method, the Regulus furnace extraction
system must be installed!
3 Remove transport protection device from the
mould chamber prior to start-up!
Miditherm 100 MP:
28 .... 33 kg
Miditherm 200 MP:
56 .... 65 kg
BEGO Regulus
Ref. 25750
Installation
