Miditherm MP
Unit description
Miditherm laboratory ovens serve for waxing and pre-
heating of casting flasks and duplicate models. They
provide users with the facility for using both shock-
heating and conventional embedding materials. The
required finishing time, even for longer periods, can
be programmed with the aid of a micro-controller.
1 Mains cable(rear)
2 Exhaust outlet (rear)
3 Flask chamber
4 Control panel
5 Main switch
1
1
2
2
3
3
4
5
4
5
Miditherm 100 MP Miditherm 200 MP
Control panel
1 Combined display: Heating rate / Oven
temperature / Duration of holding stage
2 Holding stage display
3 Program display
4 Combined display: Time / Finishing time/ Day
5 Main switch
Function of the keys
Call-up parameters
Change values
Program
Start / stop program
Start / stop program with Finished time
1 2 3
4
5
