72
Technical Data
Indications refer to 23°C±5°C at <75% rel. humidity
For the instruments UNITEST Hexagon 320/340 (True RMS) the accuracy
is specified within the ranges 5...100% of final measurement range value.
Crest factor < 3:1 at final measurement range value and < 6:1 at half the
final measurement range value and within the indicated frequency band-
width for non-sinus shaped currents and voltages.
Voltage DC
Range Tolerance
Overload Protection
50.00 mV ±(0.12% + 2d) 600 V DC / ACeff
500 mV ±(0.06% + 2d) 600 V DC / ACeff
5.000V; 50.00V; 500.0V; 1000V ±(0.08% + 2d) 1050 Veff / 1450 Vp
NMRR: >60dB (50/60Hz)
CMRR: >120db (DC, 50/60Hz, Rs=1kV)
Input Impedance: 10MV, 16 pF nominal
(44pF nNominal at 50mV, 500mV)
Diode Test
Range Tolerance Test Current Test Voltage Overload Protection
2.000 V ±(1% + 1d) 0.8mA 3.5 V DC 600 V DC/ACeff
