ENGLISH
Technical Data
Voltage AC
Range Tolerance Overload Protection
50 Hz / 60 Hz
50.00mV; 500.0mV; 5.000V; ±(0.5% + 3d) V:1050Veff, 1450Vp
500.0V; 1000V mV: 600 V DC/ACeff
40 Hz ... 500 Hz
50.00mV; 500.0mV ±(0.8% + 3d)
5.000V; 50.00V; 500.0V ±(1.0% + 4d)
1000V ±(1.2% + 4d)
500 Hz ... 20 kHz
50.00mV; 500.0mV 0.5dB*
5.000V; 50.00V; 500.0V 3dB*
1000V not specified
*Specified from 30% to100% of measurement range
CMMR: >60db (0...60Hz, Rs=1kV)
Input Impedance: 10MV, 16 pF nominal (44pF nominal at 50mV and
500mV measurement range)
V:1050Veff, 1450Vp
mV: 600 V DC/ACeff
V:1050Veff, 1450Vp
mV: 600 V DC/ACeff
*Don’t includes the tolerance of thermo couple
Temperature (only UNITEST Hexagon 330/340)
Range Tolerance*
-50°C ...1000°C ±(0.3% + 3d)
