BEHA Unitest Hexagon 310 - Page 74

74
Technical Data
Crest-Funktion (V, A) (Peak-Hold)
Tolerance: ±150 digits for signal > 5 ms (continuous)
Range Tolerance Burden Voltage
Overload Protection
50Hz / 60 Hz
500.0 mA 0.15 mV/mA
5000 mA ±(0.6% + 3d) 0.15 mV/mA
50.00 mA 3.3 mV/mA
500.0 mA ±(1.0% + 3d) 3.3 mV/mA
5000 A ±(0.6% + 3d) 0.03 V/A
10.000 A* ±(0.6% + 3d) 0.03 V/A
40 Hz ...1kHz
500.0 mA ±(0.8% + 4d) 0.15 mV/mA
5000 mA ±(0.8% + 4d) 0.15 mV/mA
50.00 mA ±(0.8% + 4d) 3.3 mV/mA
500.0 mA ±(1.0% + 4d) 3.3 mV/mA
5.000 A ±(0.8% + 4d) 0.03 V/A
10.000 A* ±(0.8% + 4d) 0.03 V/A
Current AC
*10A continuous, 20 A for max. 30 s with 5 min. cool down intervall
240V AC, 150V DC
240V AC, 150V DC
Range Tolerance Burden Voltage Overload Protection
500.0 mA 0.15 mV/mA
5000 mA 0.15 mV/mA
50.00 mA ±(0.2% + 4d) 3.3 mV/mA 240V AC,150V DC
500.0 mA 3.3 mV/mA
5.000 A 0.03 V/A
10.00 A* 0.03 V/A
Current DC
*10A continuous, 20 A for max. 30 s with 5 min. cool down intervall
