BEIER-Electronic MSM-1 - Model No. 2 - Truck 2

GB Sound module MSM-1
18.01.2024 BEIER-Electronic 10
Model no. 2 – Truck 2 ○◐○
Assignment of prop. inputs:
A - short
A - long
D - short
D - long
Prop #1
Gas/throttle channel
Prop #2
Steering channel (indicator)
Prop #3
Horn 1
Horn 2
Prop #4
Fanfare 1
Fanfare 2
Fanfare 3
IR servo
Prop #5
Turk's whistle
Volume setting
Compressed air
Hazard lights
Prop #6
Light 1
Light 2
Light 3
Light 4
Assingnment of outputs:
1
2
3
4
5
6
7
8
Light 1 Light 2 Light 3 Light 4
Left
indicator
Right
indicator
Brake
light
Reversi
ng light
Additional model features:
• The driving sound is switched on automatically when accelerating (Prop #1)
and off again after 30 s when stationary.
• The indicators are activated via the steering (Prop #2). If the indicators are not
to be activated via the steering, but rather via an extra switch on the radio,
then the steering servo is connected directly to the receiver. Prop #2 of the
MSM-1 is then connected to the receiver channel of the radio switch that
controls the indicator lights.
• When braking, the brake light is activated. In addition, the brake light is always
on when stationary as long as the driving sound is on.
• When reversing, the reversing lights, hazard warning lights and reversing
warning sound are switched on automatically.
• If the “IR Servo” function is activated, the servo output 1 of the IR light
modules LM-IR-8-1 and LM-IR-16-4 can be controlled via Prop #2. See page
32.
