GB Sound module MSM-1
19 BEIER-Electronic 18.01.2024
Model no. 11 – Tank 2 ●○○
Assignment of prop. inputs:
A - short
A - long
D - short
D - long
Prop #1
Gas channel
Prop #2
Steering channel
Prop #3
MG1
Shot 1
Shot 2
Prop #4
Tower turning
Tower turning
Prop #5 MG2 Volume setting
Radio message
1
Radio message
2
Prop #6
Light 1
Light 2
Light 3
Light 4
Assingnment of outputs:
1
2
3
4
5
6
7
8
Light 1 Light 2 Light 3 Light 4
Cannon
Flash
MG
flash
Brake
light
Reversi
ng light
Additional model features:
• The driving sound is switched on when accelerating (Prop #1) and off again
after 30 s when stationary.
• When braking, the brake light is activated. In addition, the brake light is always
on when stationary as long as the driving sound is on.
• When reversing, the reversing light is automatically switched on.
