BEIER-Electronic MSM-1 - Model No. 7 - Tractor

GB Sound module MSM-1
15 BEIER-Electronic 18.01.2024
Model no. 7 – Tractor ◐◐◐
Assignment of prop. inputs:
A - short
A - long
D - short
D - long
Prop #1
Gas channel
Prop #2
Faucet
goose
Cow
Dog
Prop #3
Horn 1
Horn 2
Prop #4
Cricket
Plow
Bird 1
Bird 2
Prop #5
Left indicator
Volume setting
Right indicator
Hazard lights
Prop #6
Light 1
Light 2
Light 3
Light 4
Assingnment of outputs:
1
2
3
4
5
6
7
8
Light 1 Light 2 Light 3 Light 4
Left
indicator
Right
indicator
Brake
light
Reversi
ng light
Additional model features:
• The driving sound is switched on when accelerating (Prop #1) and off again
after 30 s when stationary.
• When braking, the brake light is activated. In addition, the brake light is always
on when stationary as long as the driving sound is on.
• When reversing, the reversing light is automatically switched on.
