BEIER-Electronic MSM-1 - Model No. 6 - Emergency Vehicle

GB Sound module MSM-1
18.01.2024 BEIER-Electronic 14
Model no. 6 – Emergency vehicle ◐◐○
Assignment of prop. inputs:
A - short
A - long
D - short
D - long
Prop #1
Gas channel
Prop #2
Steering channel (indicator)
Prop #3
Horn 1
Horn 2
Prop #4
Martinshorn 1
Martinshorn 2
Martinshorn 3
Martinshorn 4
Prop #5
Announcement
1
Volume setting
Announcement
2
Hazard lights
Prop #6
Light 1
Light 2
Warning light
Flashing light
Assingnment of outputs:
1
2
3
4
5
6
7
8
Light 1 Light 2
Warning
light
Flashing
light
Left
indicator
Right
indicator
Brake
light
Reversi
ng light
Additional model features:
• The driving sound is switched on when accelerating (Prop #1) and off again
after 30 s when stationary.
• The indicators are activated via the steering (Prop #2). If the indicators are not
to be activated via the steering, but rather via an extra switch on the radio,
then the steering servo is connected directly to the receiver. Prop #2 of the
MSM-1 is then connected to the receiver channel of the radio switch that
controls the indicator lights
• When braking, the brake light is activated. In addition, the brake light is always
on when stationary as long as the driving sound is on.
• When reversing, the reversing lights and hazard warning lights are switched
on automatically.
• When the siren is switched on, the “warning light” and “speed camera” outputs
are automatically switched on.
• If the warning light and/or speed camera was activated before the siren was
switched on, these outputs remain switched on even after the siren has been
switched off again.
