BEIER-Electronic MSM-1 - Model No. 5 - Car 2

GB Sound module MSM-1
13 BEIER-Electronic 18.01.2024
Model no. 5 – Car 2 ◐○◐
Assignment of prop. inputs:
A - short
A - long
D - short
D - long
Prop #1
Gas channel
Prop #2
Steering channel (indicator)
Prop #3
Horn 1
Horn 2
Prop #4
Turk's whistle
Music 1
Fanfare
Music 2
Prop #5
Chirp
Volume setting
Door open/close
Hazard lights
Prop #6
Light 1 Light 2 Light 3 Light 4
Assingnment of outputs:
1
2
3
4
5
6
7
8
Light 1 Light 2 Light 3 Light 4
Left
indicator
Right
indicator
Brake
light
Reversi
ng light
Additional model features:
• The driving sound is switched on when accelerating (Prop #1) and off again
after 30 s when stationary.
• The indicators are activated via the steering (Prop #2). If the indicators are not
to be activated via the steering, but rather via an extra switch on the radio,
then the steering servo is connected directly to the receiver. Prop #2 of the
MSM-1 is then connected to the receiver channel of the radio switch that
controls the indicator lights
• When braking, the brake light is activated. In addition, the brake light is always
on when stationary as long as the driving sound is on.
• When reversing, the reversing lights is switched on automatically.
