WAVE ACROSS
1MANUL850 Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 15
Installation
Cloth
Helpful Hint
Collar Placement
Placement typical on all six bearings (Overhead view of Head Frame)
DO NOT LOOSEN ANY OF THE SIX
COLLARS DURING CLOTH
INSTALLATION OR REPLACEMENT!
If circumstances require doing, so see
dimensions below
Overhead View
Collar Assembly
Collars are to be butted up
against the side-plates
Collars are to be butted up
against the side-plates
To Next Page
