5) REMOVAL OF REAR SERVICE PANEL
REMOVE ALL SCREWS FROM THE
REAR PANEL (14 IN TOTAL )
REMOVE THE REAR SERVICE PANEL
TAKE CARE AS THE COOLING FAN
WIRES NEED TO BE DISCONNECTED
TO REMOVE THE PANEL FULLY
NOTE THE SIDE PANELS ON ALL B/I
PRODUCTS CANNOT BE REMOVED
IGNITION GENERATOR
FAN TIMER PCB
MAIN OVEN SOLENOID
