6

REPLACEMENT OF COMPONANTS

A) TIMER

FOLLOW STEP E REMOVAL OF FACIA

PANEL

REMOVE 4X SECURING SCREWS

(TORX)

REMOVE TIMER FROM FACIA

B) THERMOSTATS

FOLLOW STEPS 3/5 AND REMOVE

THE FACIA PANEL AND REAR

SERVICE PANEL

REMOVE THE LICON M/SWITCHES

FROM THE FACIA PANAEL
