8
C) GRILL MICROSWITCH
THE GRILL MICROSWITCH CAN NOW
BE REMOVED BY RELEASING THE
HOLDING CLIPS AS SHOWN
D) GRILL ELEMENT
FOLLOW STEP 5 AND REMOVE REAR
SERVICE PANEL
DISCONNECT WIRES
REMOVE GRILL ELEMENT GUARD BY
LOOSENING 2 HIDDEN SCREWS
(POSITIONS INDICATED ) AND
SLIDING OFF
REMOVE THE 2 SCREWS SECURING
THE ELEMENT BRACKET TO THE
CAVITY AND PULL THE ELEMENT
FORWARD TO REMOVE
